SEMICONDUCTOR DESIGN · EDA SOFTWARE

Engineering precision.
Operational clarity.

Deterministic CMOS analog synthesis for semiconductor teams balancing circuit complexity, senior engineering capacity, and operating cost.

Analytical Physics Engine Zero Hallucinations Cross-PDK Portability
CAST CSSM Core v2.4 · TSMC 180nm BCD
CONVERGED (0.42s)
SPECIFICATIONS DC Gain ≥ 75 dB GBW ≥ 180 MHz PM > 65° Power < 420 µW CMRR > 85 dB -40°C .. +125°C CSSM MOS SOLVER First-Principles Physics gm/ID · Vov · Vth Matrix Optimum 100% Corners Verified SPICE NETLIST M1: W=14.2u L=0.18u M2: W=14.2u L=0.18u M3: W=28.4u L=0.35u Ibias: 42.5 µA Cc: 1.45 pF DRC / LVS READY Cadence / Synopsys
Turnaround Compression
20× – 100×
From 6 weeks of manual sweeps to <1 minute
OpEx Recovery / Seat
−95%
Sunken opportunity cost eliminated per analog designer
NRE Risk Mitigation
Zero Re-Spins
100% PVT corner closure eliminating multi-million € mask re-spin exposure
Convergence Velocity
4–8 mins
Deterministic closed-form MOS multi-corner solution
The Semiconductor Reality

Digital design automated decades ago.
Analog remains an artisan craft.

While digital flows rely on synthesis engines and automated place-and-route, analog blocks still consume weeks of manual transistor tuning and costly simulation queues.

01 / OPEX & COMPUTE DRAIN LICENSE BURN

The Simulation OpEx Burn

Manual transistor sizing forces brute-force SPICE sweeps across hundreds of PVT corners. This exhausts expensive simulator license tokens (Spectre, HSPICE) and ties up server cluster compute for weeks without convergence guarantees.

Financial Drag: Escalating compute infrastructure costs and bloated EDA software licensing budgets.
02 / HUMAN CAPITAL €180k+ LOADED COST

Senior Talent Misallocation

Senior analog designers cost €150k–€250k/year in loaded compensation. Yet design teams lose up to 60% of an architect's billable quarter waiting on simulation queues and mechanically tweaking channel dimensions.

Capacity Drag: Scarce engineering bandwidth trapped in clerical tuning rather than high-margin architectural IP.
03 / CAPEX RE-SPEND 100% NRE DUPLICATION

NRE Duplication in Migrations

Migrating proven analog circuits between foundries or from planar CMOS to advanced nodes (28nm, FinFET) historically requires starting sizing from scratch—duplicating original NRE investment and delaying customer revenues.

Capital Drag: Circuit IP remains captive to a single foundry fab, forfeiting multi-source volume price leverage.
Dual Alignment

Built for the lab bench. Aligned with the board room.

A successful EDA platform must respect the engineer's need for physical rigor while providing executive leadership with predictability, capacity, and capital efficiency.

ONE DETERMINISTIC ENGINE Two vital dimensions of mixed-signal tape-outs solved simultaneously.
Zero trade-off between physical accuracy and business predictability
Technical Decision Makers ENGINEERING REALITY

Physical Rigor without the Guesswork

Engineers retain complete architectural control. CAST synthesizes optimal transistor dimensions from first-principles physical equations rather than stochastic black boxes.

  • Deterministic Transistor Sizing

    Solves multi-variable operating points (W, L, Vgs, Ibias) analytically using CSSM MOS modeling.

  • Complete PVT Corner Closure

    Simultaneously enforces constraints across process skews (SS, TT, FF), voltage fluctuations, and temperature extremes (-40°C to 125°C).

  • Standard Netlist Integration

    Outputs clean, foundry-compatible SPICE netlists that plug straight into existing layout, DRC, and LVS toolchains.

Executive Leadership & Finance CAPITAL & PROGRAM CERTAINTY

Operational Clarity & Tape-Out Predictability

Transform volatile analog engineering OpEx into reusable intellectual property. Deliver mixed-signal tape-outs on schedule without ballooning simulator licensing bills or expanding design headcounts.

  • MPW Shuttle Window Protection (TTM)

    De-risks tape-out deadlines by 6–8 weeks. Missing a foundry shuttle deadline costs 3–4 months of market delay and millions in customer commercial commitments.

  • Substantial OpEx & License Optimization

    Recovers €100k–€200k in opportunity cost per engineer annually while cutting expensive simulator farm compute and license token exhaustion by up to 80%.

  • Foundry Sovereignty & NRE Amortization

    Re-synthesize analog IP across alternate foundries automatically. Avoid duplicating original NRE budgets and gain multi-sourcing pricing leverage.

Technology Foundation

The Three Pillars of Deterministic Synthesis

How CAST transforms artisan transistor sizing into an automated, mathematically verified engineering flow.

PILLAR 02 · PORTABILITY

Foundry & PDK Portability

Design requirements are codified independently of specific silicon fab restrictions. When migrating to an alternate foundry or changing technology nodes, CAST re-synthesizes optimal dimensions for the target PDK automatically.

PILLAR 03 · VELOCITY

Turnaround Time Compression

Complex analog topologies—operational amplifiers, bandgap references, low-dropout regulators (LDOs), and comparator stages—are synthesized and verified against multi-corner specs in minutes, freeing engineers for architectural innovation.

Manual Iteration: 240 Hours (Weeks)
CAST Synthesis: 0.17 Hours (~10 mins)
Process Architecture

Fitting seamlessly into existing EDA toolchains

CAST does not require replacing your verified design rule checkers, extraction engines, or layout editors. It eliminates the manual sizing bottleneck before netlist verification.

TRADITIONAL SPICE LOOP HIGH OPEX RISK

Iterative Manual Tuning

Manual trial-and-error sizing reliant on designer intuition and brute-force simulator queues.

01. Hand calculation of first-order transistor parameters
02. Manual schematic entry in proprietary CAD suite
03. Launch SPICE simulation sweeps across PVT corners
04. Corner failure: manually re-tune W/L, re-run sweeps (Weeks)
CAST DETERMINISTIC FLOW PROVABLE CONVERGENCE

Automated Physics Synthesis

Analytical physics formulation delivering multi-corner verified netlists directly into layout.

01. Define architectural specifications (Gain, BW, Phase Margin)
02. Select target foundry PDK & process corner envelopes
03. CAST CSSM Engine: computes global analytical optimum (4 to 8 minutes)
04. Direct export to standard SPICE netlist for place & route
Capacity & OpEx Model

Quantify your design cycle acceleration

Model the engineering throughput and schedule compression achieved by automating analog transistor sizing on your upcoming tape-out.

TAPE-OUT CAPACITY & OPEX SIMULATION ENGINE
LIVE PARAMETRIC MODEL
Number of Analog Blocks in Tape-out 6 analog blocks
1 block 10 blocks 20 blocks
Circuit Complexity & PVT Severity
Baseline Assumption: Standard manual analog sizing averages ~5 working days per block (including manual SPICE sweeps and PVT corner resolution). CAST synthesizes each block in ~90 seconds.
Manual Sizing & Sweep Duration
30 days
CAST Deterministic Synthesis Time
9 mins
Initiate Technical Engagement

Discuss your EDA workflow with our team

Whether you are planning an upcoming tape-out, exploring mixed-signal synthesis pilots, or assessing cross-PDK migration feasibility, our engineering leadership is ready to evaluate your requirements.
